All stainless steel 40mm SS pressure gauges are available with either bottom or back entry. Please contact us for price and delivery for ranges up to 400 bar, each unit is supplied with a UKAS traceable calibration certificate.
These gauges are typically used in general processing and R&D areas, applications include petrochemical, pharmaceutical, food and beverage.
They are suitable for liquids and gasses. The 316L wetted parts make this gauge suitable for a wide range of applications. For applications where you have vibration, we would recommend the optional liquid filling.
Nominal Size: 40mm
Accuracy: 2.5% FSD
Scale: Bar Outer (Black) PSI Inner (Red)
Mounting: Bottom Direct
Operating temperature: -20/+60C Ambient
Ingress Protection: IP65
Case & Bezel: 304SS
Pressure Element: 316L SS
Process connection: Bottom
Filling: Optional
OEM and volume prices are available on request.
