Panel mounting 40mm diameter general purpose dry pressure gauge for the measurement of fluid liquids that are not highly viscous or corrosive to copper or tin alloys.
Also suitable for gases (excluding oxygen or acetylene) up to 25 bar maximum.
For use in: Pneumatics, Air Compressors, HVAC Industry, Water Industry
Nominal Size: 40mm
Accuracy: +/- 2.5% FSD
Scales: PSI Outer (Black) & BAR Inner (Red) – Pressure and “HG Outer (Black) & BAR Inner (Red) – Vacuum
Mounting Options: Centre Back – Panel mounting rear bracket included
Operating Temperature: Ambient: -20/+60ºC Medium: +60ºC maximum
Case: Enamelled steel
Bezel: 304 Stainless Steel – Crimped
Window: Acrylic – Crystal clear
Process Connection: 1/8 BSPT Brass
Other process connections, scales and ranges available by request.
